Network systems consist of hundreds of thousands of hardware pieces. In order for them to interact and perform as a single unit, they are connected by wires. The number of cords exceeds the number of devices several times, so it can reach several thousand, depending on the system size. Cords are used to ensure smooth communication between units and guarantee coordinated performance.

As the number of wires is huge, it’s important to know network rack cable management best practices to prevent multiple problems. Below, we’re going to concentrate on them.

Advantages of Cable Management

Proper cable management helps solve multiple tasks and achieve a better server sack layout. The following benefits are highlighted:

  • enhanced system performance due to smooth contact between different parts and units;
  • increased cooling efficiency due to neat and organized cords;
  • improved scalability since wires are stretched correctly and neatly;
  • better availability and easier maintenance since tangles are prevented.

Note that tangled disorganized wires frequently become the reason for system overheating (because of insufficient airflow supply), system downtime (because of accidental rapture), etc. Neatly arranged wires mean a well-functioning IT system. However, system administrators should be aware of some network rack cable management tips to organize them properly.

Note that if you need any tools for server rack power cable management, you can find them here https://sysracks.com/catalog/cabling/. Sysracks offers a wide range of accessories for cord arrangement for any system and rack type. Managers are experienced and ready to assist in selecting the needed tools.

Steps for Achieving Server Rack Cable Management

Each process requires due attention and consideration. When it comes to cabling, wires are used as “veins” of the “network body”. Thus, any mistake can spoil the functioning routine. According to rack cable management best practices, wiring should go through the following stages:

  1. Planning. Consider the system to realize how many cables you need, what type of cords are required, etc. It’s an initial step of network rack cabling to ensure proper and durable performance.
  2. Determine the routes for power. It’s advisable to create a 3D layout to identify the best routes to connect the system to power supplies.
  3. Identify cords. Some cords can stretch through the entire system, which hardens troubleshooting and maintenance. Moreover, it’s difficult to identify the needed wire in bundles of hundreds of cords. Thus, labeling cables with markers and colors is used to simplify maintenance
  4. Secure wires. Once they are laid, make sure to secure them from accidental rapture, cutting, etc. Provide a high level of security since rapture can lead to datum loss and system downtime.
  5. Avoid thermal problems. Make sure that gathered cords do not interact and prevent heat exchange. Thus, consider what power is transferred via different categories of cords.
  6. Document and maintain organization. Once you’re done with server rack cabling, remember to document the scheme of cord wiring. Keeping the scheme at hand during maintenance helps the staff simplify and accelerate the process.

Strict compliance with this server rack cable management guide helps arrange a highly secure system that can be easily maintained. Proper functioning and smooth interaction of all telecommunication devices are guaranteed.

Accessories for Server Rack Cable Management

The staff needs special tools and accessories to route, fasten, and arrange cords neatly. According to rack cabling best practices, specialists use the following accessories to arrange wires:

  1. Vertical wire manager. These are special plastic boxes fastened to rack uprights. It allows for stretching cords along rack angles without taking up much space in a cabinet. Managers can be of different sizes and lengths, so they can accommodate different numbers of wires.
  2. Horizontal cord manager. The same plastic boxes are mounted horizontally. They are usually fastened to mounting rails or shelves.
  3. Patch panels. These accessories allow for connecting different types of wires. Panels have multiple slots and serve as connecting points with various joints.
  4. Fiber optic patch panels. Such panels are specially designed for fiber wires.
  5. Hook and loop wire ties. These tools for server cable management are very popular since they allow for bungling long cables. If the staff needs to stretch wires for a long distance, wires are bundled with hooks and ties over a certain distance to prevent tangling or rapture.

The modern market offers a wide variety of accessories for keeping cords neat and arranged. So, it’s possible to find an appropriate solution for any case.

To sum up, note that cable arrangement comes as one of the crucial steps of data center setup. The issue requires consideration since tangled cords can impede airflow and lead to overheating, slow down maintenance, and prolong downtime. Thus, it’s worth using server rack cable management tips when wiring cords to avoid multiple mistakes and enjoy an effective layout that will guarantee safe and effective operation and maintenance.
